  Product Name:Automatic Perimeter
Product Code:ASP-6000BER


CE Certificated, FDA registered

Description:

--The Automatic Perimeter is designed and developed on windows system.Users can get an intuitive report with examined perimetry results. Computerized perimetry now has became a popular and mandatory examination method for medical and optical purpose.
--with software, without computer, without printer



Specification:
1. Stimulus Type: LED
2. Stimulator screen: hemispherical bowl, radius 30cm integrated
3. Stimulus source: light emitting diode, wave length 580~650nm
4. Stimulus size: goldmann III
5. Stimulus intensity: 2.5~1000asb
6. Stimulus duration: adjustable 0.2 to 2 seconds
7. Stimulus color: yellow, red
8. Stimulus step: total 27, step 1
9. Minimum inter-stimulus delay: adjustable 0.2 to 2 seconds
10. Background illumination: 4asb
11. Lens holder diameter: 35mm(optional)
12. Central sign diameter: 3m m
13. Stimulus points: 144(0~60º), 72(0~30º), 72(60~90º), 61(0~10ºred), 144(Blind spot)
14. Chin rest moving range: vertical 70mm, horizontal 90mm
15. Fixation method: automatic monitoring with two options.
                    Available blind spot method, Eye tracking method.
                     In both methods, fixation errors are to be immediately announced by visual and audible warnings.
                     The standard video camera should provide visual of the patient’s eye for additional monitoring

16. Strategies: estimative test, qualitative test, auto threshold, fast threshold, full threshold, esterman test and other popular mode.
17. Test range: default test(0~60º), Yellow spot test(central0~10º), Central 0~30º test, Quadrant test, Peripheral test(60~90º), Blind spot test, Custom test
18. Stimulator unit dimensions: 68*76*50cm (H*W*D)
19. Stimulator unit weight: 25KGS approx
20. Stimulator unit power supply: 220V AC 50/60HZ

Software Interface:
1. Software window:    0~60 degree image     color image
2. Eye-tracking:           60~90 degree image    3D image
3. Parameter setup:    0~90 degree image      Database inquiry
4. Print option:            Smoothed image       Report data
